S380-L4P1T

Part number: 98012178

Product specifications

Switching Capacity

8Gbps

Packet forwarding rate

Upload:300 Kpps, download:420 Kpps

Egress bandwidth

1Gbps

Maximum user

200

Managed APs

GE RJ45

5 (4 PoE+) (1G/100M/10M)

WAN ports

1 x GE WAN

LAN ports

4 x GE LAN (50 W PoE+)

PoE

Supported

Maximum PoE power consumption [W]

Dimensions without packaging (H x W x D) [mm(in.)]

Basic dimensions (excluding the parts protruding from the body): 35.0 mm x 210.0 mm x 130.0 mm (1.38 in. x 8.27 in. x 5.12 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 35.0 mm x 210.0 mm x 136.3 mm (1.38 in. x 8.27 in. x 5.37 in.)

Dimensions with packaging (H x W x D) [mm(in.)]

90.0 mm x 285.0 mm x 180.0 mm (3.54 in. x 11.22 in. x 7.09 in.)

Installation type

Desk mounting,Wall mounting

Chassis material

Metal

Weight without packaging [kg(lb)]

0.9 kg (1.98 lb)

Weight with packaging [kg(lb)]

1.1 kg (2.43 lb)

Typical power consumption [W]

7.19

Maximum power consumption [W]

61.65 W (PoE: 50 W)

Long-term operating temperature [°C(°F)]

0°C to 40°C (32°F to 104°F) at an altitude of 0-1800 m (0-5906 ft.)

Long-term operating relative humidity [RH]

5% RH to 95% RH, non-condensing

Power supply mode

Power adapter

Input voltage range [V]

Power adapter input: 90–290 V AC; 47–63 Hz

Power supply surge protection [kV]

Power adapter: ±6 kV in differential mode and ±6 kV in common mode

Heat dissipation mode

Natural heat dissipation

Certification

EMC certification Safety certification Manufacturing certification
