S210-24T2J
S210-24T2J
Part number: 98012925
S210-24T2J (24*10/100/1000BASE-T ports, 2*2.5GE SFP ports, built-in AC power, Fanless)
Product specifications
GE RJ4524 (1G/100M/10M)
2.5G SFP2 (2.5G/1G/100M)
CertificationEMC certification Safety certification Manufacturing certification
Chassis materialMetal
Static power consumption [W]8.14
Dimensions without packaging (H x W x D) [mm(in.)]Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442 mm x 160 mm (1.72 in. x 17.40 in. x 6.30 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442 mm x 167 mm (1.72 in. x 17.40 in. x 6.57 in.)
Dimensions with packaging (H x W x D) [mm(in.)]90.0 mm x 550.0 mm x 260.0 mm (3.54 in. x 21.65 in. x 10.24 in.)
Installation typeRack mounting,Desk mounting,Wall mounting
Weight without packaging [kg(lb)]2.06 kg (4.54 lb)
Weight with packaging [kg(lb)]2.55 kg (5.62 lb)
Typical power consumption [W]18.30
Maximum power consumption [W]18.90
Long-term operating temperature [°C(°F)]–5°C to +45°C (23°F to 113°F) at an altitude of 0 to 1800 m (0 to 5905.44 ft.)
Long-term operating relative humidity [RH]5% RH to 95% RH, non-condensing
Power supply modeAC built-in
Input voltage range [V]AC input: 90 V AC to 264 V AC; 45 Hz to 65 Hz
Power supply surge protection [kV]Differential mode: ±6 kV; common mode: ±6 kV
Heat dissipation modeNatural heat dissipation
