eKitStor Xtreme 300P PCIe 5.0 12.8TB SSD NVMe Disk UniteKitStor Xtreme 300P PCIe 5.0 12.8TB SSD NVMe Disk Unit(2.5")
View More
| Supported Servers | Servers supporting U.2 NVMe SSD disks |
| Certifications | China: RoHS Europe: WEEE, RoHS, REACH, and CE Northern America: NRTL UK: UKCA Japan: VCCI Canada: IC Australia: RCM Member States of IEEE: CB |
| Data Retention (Power-off) | 3 months at 40ºC (104ºF） |
| Form Factor | U.2 2.5-inch |
| Interface | PCIe 4.0 1x4 |
| NVMe Protocol | NVMe 1.4 |
| NAND Flash | 3D TLC |
| Available Capacity | 1.6TB | 1.92TB | 3.2 TB | 3.84 TB | 6.4 TB | 7.68 TB | 15.36TB |
| Average Power Consumption (Idle, Active) | 7.5 W (idle) , 18 W (Active) |
| Weight (g) | < 182 g |
| TRIM | Supported |
| Power Failure Protection | Supported |
| Chip Failure Protection | Supported |
| Reliability | Meantime between failures (MTBF): 2.5 million hours; Annual failure rate (AFR): ≤ 0.35% ; Uncorrectable bit error rate (UBER): 10^-18 |
| Temperature | Non-operational: –40ºC to 85ºC (–40°F to 185ºF); Operational: 0ºC to 83ºC（32°F to 181.4ºF） |
